OTHER EXV-SF 14 / EXV-SF 16 EXV-SF 14i / EXV-SF 16i
8.1 Type of drive control AC control AC control
8.4
Noise level at operator's
ear
dB
(A)
≤ 66 ≤ 66
(1) In brackets: capacity on the forks for the
version with fork initial lift (i)
(2) Values for Tele or NiHo mast (x value
-26 mm, l
1
+ l
2
+26 mm with Triplex mast)
(3) Fork arms raised (see the figure with apos-
trophe for dimensions)
(4) Value with battery such as 6.3 (+75 mm
with 3 PzS and +150 mm with 4PzS)
(5) Truck with tandem rollers
(6) Value with Tele mast h
3
= 2844 mm. For
other values see mast table
(7) With load rack, mandatory for -SF
(8) Value with platform lowered
(9) The fork thickness value indicated is for
use with GITTER-BOX. A carriage with thick-
ness s = 71 mm is also available
(10) Thickness values with forks fully lowered
m
2
= 15 mm
(11) Values with fender
(12) Value with straddles lowered +17 mm
(13) Value with straddles lowered +42 mm
(14) Value with straddles lowered +78 mm
(15) ±5%
(16) Speed in pedestrian mode - Speed stand-
ing without side protection - Speed standing
with side protection
(16) On slopes with gentle start and forks
raised (geometric limit with start of slope at =
9.2%)
(17) Value with Tele mast h3 = 4644 mm
(18) Rounded edge on the side with forks low-
ered (geometric limit on slope =9.2%)
(19) In brackets: maximum surmountable gra-
dient with capacity of 2000 kg on the fork side,
with the initial lift option.
