Datasheet (VDI) EXV 20 / EXV 20i
CHARACTERISTICS EXV 20 EXV 20i
1.3
Power unit: elec-
tric, diesel, petrol,
LPG
Electric Electric
1.4
Drive type: man-
ual, pedestrian,
stand-on, seated,
order picker
Pedestrian Pedestrian
1.5 Load capacity
Q
(kg)
2000 2000 (2000)
(1)
1.6 Load centre
c
(mm)
600 600
1.8
Load distance,
centre of drive
axle to fork
x
(mm)
724
(2)
724
(2)
/646
(2) (3)
1.9 Wheelbase
y
(mm)
1425 1425 / 1347
(3)
WEIGHT EXV 20 EXV 20i
2.1
Service weight (with bat-
tery)
kg 1505 1439
2.2
Axle load with load, drive
side/load side
kg 1307 / 2198 1135 / 2303
2.3
Axle load without load,
drive side/load side
kg 1063 / 441 1019 / 420
WHEELS EXV 20 EXV 20i
3.1 Tyres Polyurethane Polyurethane
3.2 Drive wheel sizes mm Ø 230 x L90 Ø 230 x L90
3.3
Wheel sizes, load side mm Ø 85 x L85 (Ø 85 x L60)
(4)
Ø 85 x L105 (Ø 85 x L80)
(4)
3.4 Stabiliser wheels (sizes) mm Ø 150 x L50 Ø 150 x L50
3.5
Wheels number, drive side/
load side (x = drive wheel)
1x + 1/2 (1x + 1/4)
(4)
1x + 1/2 (1x + 1/4)
(4)
3.6
Track width, drive side
b10
(mm)
534 534
3.7
Track width, load side
b11
(mm)
370 370
DIMENSIONS EXV 20 EXV 20i
4.2 Height of mast, lowered
h1 (
mm)
1915
(5)
1915
(5)
Technical data
6
Datasheet
