4.3 Free lift
h2 (
mm)
150
(5)
150
(5)
4.4 Lift
h3 (
mm)
2684
(5)
2684
(5)
4.5 Height of mast, extended
h4 (
mm)
3284
(5)
3284
(5)
4.6
h5
(mm)
/110
4.9
Height of tiller arm in driv-
ing position, min/max
h14 (
mm)
865 / 1265 865 / 1265
4.1
5
Fork height, lowered
h13
(mm)
86 86
4.1
9
Overall length without load
l1
(mm)
2065
(2)
2065
(2)
4.2
0
Length including fork
shoulder
l2
(mm)
915
(2)
915
(2)
4.2
1
Total width
b1
(mm)
810 810
4.2
2
Fork dimensions
s/e/
l (m
m)
73/210/1150 73/210/1150
4.2
4
Fork carriage width
b3
(mm)
780 780
4.2
5
Fork spread
b5
(mm)
580 / 680 580 / 680
4.2
6
b4
(mm)
230 / 330 230 / 330
4.3
2
Ground clearance, centre
of wheelbase
m2
(mm)
20
(7)
20
(7)
/ 150
(2)
4.3
4
Aisle width with pallets 800
x 1200
Ast (
mm)
2579 / 2462
(8)
2562
(3) (9)
/2447
(3) (8) (9)
4.3
4.1
Aisle width with pallets
1000 x 1200
Ast (
mm)
2617 / 2500
(8)
2576
(3) (10)
/2461
(3) (8) (10)
4.3
5
Turning radius
Wa (
mm)
1757 / 1640
(8)
1679
(3) (11)
/1564
(3) (8) (11)
PERFORMANCE EXV 20 EXV 20i
5.1
Travel speed with/without
load
km/h 6.0 / 6.0
(13)
6.0 / 6.0
(13)
5.2
Lifting speed, with/without
load
m/s 0.15/0.30
(12)
0.15/0.30
(12)
Technical data
6
Datasheet
150 45758043484 EN - 11/2021 - 08
