5.3
Lowering speed, with/with-
out load
m/s 0.31/0.31
(12)
0.31/0.31
(12)
5.8
Climbing ability KB 5', with/
without load
% 8 / 23
(13)
8 / 23
5.1
0
Service brake Electric Electric
TRANSMISSION
EXV 20 EXV 20i
6.1 Traction motor, S2=60 min kW 2.3 - 1.5
(18)
2.3 - 1.5
(18)
6.2 Lifting motor, S3=15% kW 3.2 3.2
6.3
Battery acc. to DIN 43
531/35/36 A, B, C, no
3 PzS
(14)
3 PzS
(14)
6.4 Voltage/Nominal capacity V/Ah 24 / 345 24 / 345
6.5 Battery weight (±5%) kg 288 288
6.6
Energy consumption acc.
to VDI cycle
kWh/
h
1.44 1.57
OTHER
EXV 20 EXV 20i
8.1 Type of drive control AC control AC control
8.4
Noise level at operator's
ear
dB
(A)
≤ 66 ≤ 66
(1) In brackets: capacity on the forks for the
version with fork initial lift (i)
(2) Values for Tele or NiHo mast (x value
-26 mm, l
1
+ l
2
+26 mm with Triplex mast)
(3) Fork arms raised (see the figure with apos-
trophe for dimensions)
(4) In brackets: tandem rollers
(5) Value with Tele mast h
3
= 2684 mm. For
other values see mast table
(6) With load rack, mandatory for -SF
(7) Value with platform lowered
(8) With forks fully lowered m
2
= 13 mm
(9) Values with fender
(10) Value with straddles lowered +17 mm
(11) Value with straddles lowered +42 mm
(12) Value with straddles lowered +78 mm
(13) ±5%
Technical data
6
Datasheet
15145758043484 EN - 11/2021 - 08
