(18) Rounded edge on the side with forks low-
ered (geometric limit on slope =9.2%)
(19) In brackets: maximum surmountable gra-
dient with capacity of 2000 kg on the fork side,
with the initial lift option.
Datasheet (VDI) EXV 20 / EXV 20i
CHARACTERISTICS EXV 20 EXV 20i
1.3
Power unit: elec-
tric, diesel, petrol,
LPG
Electric Electric
1.4
Drive type: man-
ual, pedestrian,
stand-on, seated,
order picker
Pedestrian Pedestrian
1.5 Load capacity
Q
(kg)
2000 2000 (2000)
(1)
1.6
Load centre of
gravity
c
(mm)
600 600
1.8
Load distance,
centre of drive
axle to fork
x
(mm)
724
(2)
724
(2)
/646
(2) (3)
1.9 Wheelbase
y
(mm)
1425 1425/1347
(3)
WEIGHT EXV 20 EXV 20i
2.1
Service weight (with bat-
tery)
kg 1505 1439
2.2
Axle load with load, drive
side/load side
kg 1307/2198 1135/2303
2.3
Axle load without load,
drive side/load side
kg 1063/441 1019/420
WHEELS EXV 20 EXV 20i
3.1 Tyres Polyurethane Polyurethane
3.2 Drive wheel sizes mm Ø 230 x L90 Ø 230 x L90
3.3
Wheel sizes, load side mm Ø 85 x L85 (Ø 85 x L60)
(4)
Ø 85 x L105 (Ø 85 x L80)
(4)
3.4 Stabiliser wheels (sizes) mm Ø 150 x L50 Ø 150 x L50
3.5
Wheels number, drive side/
load side (x = drive wheel)
1x + 1/2 (1x + 1/4)
(4)
1x + 1/2 (1x + 1/4)
(4)
Technical data
6
Datasheets
168 45758043484 EN - 11/2021 - 08
