Still EXV 14D - Page 179

3.6
Track width, drive side
b10
(mm)
534 534
3.7
Track width, load side
b11
(mm)
370 370
DIMENSIONS EXV 20 EXV 20i
4.2 Height of mast, lowered
h1 (
mm)
1915
(5)
1915
(5)
4.3 Free lift
h2 (
mm)
150
(5)
150
(5)
4.4 Lifting
h3 (
mm)
2684
(5)
2684
(5)
4.5 Height of mast, extended
h4 (
mm)
3284
(5)
3284
(5)
4.6
h5
(mm)
/ 110
4.9
Height of tiller arm in driv-
ing position, min/max
h14 (
mm)
865/1265 865/1265
4.1
5
Fork height, lowered
h13
(mm)
86 86
4.1
9
Overall length without load
l1
(mm)
2065
(2)
2065
(2)
4.2
0
Length including fork
shoulder
l2
(mm)
915
(2)
915
(2)
4.2
1
Total width
b1
(mm)
810 810
4.2
2
Fork dimensions
s/e/
l (m
m)
73/210/1150 73/210/1150
4.2
4
Fork carriage width
b3
(mm)
780 780
4.2
5
Fork spread
b5
(mm)
580/680 580/680
4.2
6
b4
(mm)
230/330 230/330
4.3
2
Ground clearance, centre
of wheelbase
m2
(mm)
20
(7)
20
(7)
/150
(2)
4.3
4
Working aisle with pallet
800 x 1200
Ast (
mm)
2579/2462
(8)
2562
(3) (9)
/2447
(3) (8) (9)
Technical data
6
Datasheets
16945758043484 EN - 11/2021 - 08
