Still EXV 14D - Page 182

2.2
Axle load with load, drive
side/load side
kg 1384/2191 1213/2295
2.3
Axle load without load,
drive side/load side
kg 1141/434 1096/412
WHEELS EXV-SF 20 EXV-SF 20i
3.1 Tyres Polyurethane Polyurethane
3.2 Drive wheel sizes mm Ø 230 x L90 Ø 230 x L90
3.3
Wheel sizes, load side mm Ø 85 x L85 (Ø 85 x L60)
(4)
Ø 85 x L105 (Ø 85 x L80)
(4)
3.4 Stabiliser wheels (sizes) mm 2x Ø 140 x L50 2x Ø 140 x L50
3.5
Wheels number, drive side/
load side (x = drive wheel)
1x + 2/2 (1x + 1/4)
(4)
1x + 2/2 (1x + 1/4)
(4)
3.6
Track width, drive side
b10
(mm)
534 534
3.7
Track width, load side
b11
(mm)
370 370
DIMENSIONS EXV-SF 20 EXV-SF 20i
4.2 Height of mast, lowered
h1 (
mm)
1915
(5)
1915
(5)
4.3 Free lift
h2 (
mm)
150
(5)
150
(5)
4.4 Lifting
h3 (
mm)
2684
(5)
2684
(5)
4.5 Height of mast, extended
h4 (
mm)
3284
(5)
3284
(5)
4.6
h5
(mm)
/110
4.9
Height of tiller arm in driv-
ing position, min/max
h14 (
mm)
1175/1380 1175/1380
4.1
5
Fork height, lowered
h13
(mm)
86 86
4.1
9
Overall length without load
l1
(mm)
2108
(2)
/2516
(2) (6)
2108
(2)
/2516
(2) (6)
4.2
0
Length including fork
shoulder
l2
(mm)
958
(2)
/1366
(2) (6)
958
(2)
/1366
(2) (6)
4.2
1
Total width
b1
(mm)
810 810
4.2
2
Fork dimensions
s/e/
l (m
m)
73/210/1150 73/210/1150
4.2
4
Fork carriage width
b3
(mm)
780 780
