4.2
5
Fork spread
b5
(mm)
580/680 580/680
4.2
6
b4
(mm)
230/330 230/330
4.3
2
Ground clearance, centre
of wheelbase
m2
(mm)
20
(7)
20
(7)
/150
(2)
4.3
4
Working aisle with pallet
800 x 1200
Ast (
mm)
2519/2909
(6)
2503
(3) (9)
/2892
(3) (6) (9)
4.3
4.1
Working aisle with pallet
1000 x 1200
Ast (
mm)
2557/2947
(6)
2517
(3) (10)
/2906
(3) (6) (10)
4.3
5
Turning radius
Wa (
mm)
1697/2087
(6)
1620
(3) (11)
/2009
(3) (6) (11)
PERFORMANCE EXV-SF 20 EXV-SF 20i
5.1
Travel speed, laden/unla-
den
km/h
4.0/4.0 6.0/6.0 8.0/10.0
(13)
(14)
4.0/4.0 6.0/6.0 8.0/10.0
(13)
(14)
5.2
Lifting speed, with/without
load
m/s 0.15/0.30
(12)
0.15/0.30
(12)
5.3
Lowering speed, with/with-
out load
m/s 0.31/0.31
(12)
0.31/0.31
(12)
5.8
Climbing ability KB 5', with/
without load
%8/23
(13)
8/23
5.1
0
Service brake Electric Electric
TRANSMISSION EXV-SF 20 EXV-SF 20i
6.1 Traction motor, S2=60 min kW 2.3 2.3
6.2 Lifting motor, S3=15% kW 3.2 3.2
6.3
Battery acc. to DIN 43
531/35/36 A, B, C, no
3 PzS (14) 3 PzS
(14)
6.4 Voltage/Nominal capacity V/Ah 24/345 24/345
6.5 Battery weight (±5%) kg 288 288
6.6
Energy consumption acc.
to VDI cycle
kWh/
h
1.48 1.62
OTHER EXV-SF 20 EXV-SF 20i
8.1 Type of drive control AC control AC control
8.4
Noise level at operator's
ear
dB
(A)
≤ 66 ≤ 66
(1) In brackets: capacity on the forks for the
version with fork initial lift (i)
Technical data
6
Datasheets
17345758043484 EN - 11/2021 - 08
