Operation 5
Handling the battery
1044_606-002
2 3
– Insert the key (2) into the battery lock and
turn it 180°. Depress the battery lock. The
battery cover (3) is unlocked and can be
opened to rear.
4
1050_003-022
– Open the battery latch (4) 90°.
50
108043033 [EN] 107
