Still KANVAN-05 - Working with loads

5 Operation
Working with loads
Workingwithloads
6210_003-030
Safety regulations when handing
loads
The safety regulations for handling loads are
shown in the following sections.
DANGER
Risk to life
The working hydraulics must only be operated from
the driver’s compartment.
Never walk or stand underneath suspended loads
or raised fork arms .
Never exceed the maximum loads specified on the
load capacity label .Otherwise, stability cannot be
ensured.
DANGER
Risk of accident
Do not step onto the forks.
Do not lift people.
Nevergraborstepontomovingpartsofthetruck.
Before picking up a load
Load capacity
Example 1
Weight of load to be
lifted
500 kg
Distance between
load centre of gravity
- fork back
500 mm
Permissible load
height
1250 mm
Example 2
Weight of load to be
lifted
450 kg
Distance between
load centre of gravity
- fork back
600 mm
Permissible load
height
1250 mm
