5 Operation
Handling trailers
Automatically closing trailer coupling
2
3
1050_003-034
Hitching up
– Pull the safety lever (3).
– Swivel the lever (2) up.
– Release the brake on the front axle of the
articulated drawbar trailer.
CAUTION
If this is not done, the coupling jaw, drawbar eye
and support can be damaged!
The drawbar eye must hit the centre of the coupling
jawwhenhitchinguparigiddrawbartrailer.
– Reverse the tractor slowly.
DANGER
Do not allow anyone to stand between the tractor
and trailer during the coupling procedure.
Only drive the tractor to the trailer.
DANGER
Risk of accident!
– Make sure that after each coupling procedure
the safety (3) fully contacts the securing sleeve.
A projecting safety (3) indicates improper hitching.
The trailer may not be driven in this state.
If the locking system is blocked, do not intervene.
Risk of crushing your fingers! Please contact your
after-sales service.
– Remove the chocks at the trailer.
86
50108043033 [EN]
