Still KANVAN-05 - Datasheet (VDI)

7 Technical data
Datasheet (VDI)
Datasheet (VDI)
DESIGNATION
1.1
Manufacturer STILL STILL
1.2 Model KANVAN 05 KANVAN 10
1.3
Energy source
Electric Electric
1.4
Type of drive
Stand-on Stand-on
1.5
Nominal capacity / load
Q (kg)
500 1000
1.5.1 Towed load
Q (kg)
4000 4000
1.6
Load centre of gravity c (mm)
500 500
1.7
Nominal traction capacity
F(N)
1600 1600
1.8
Distance from front axle bolt to fork
heel
x(mm)
165 165
1.9 Wheelbase
y(mm)
1216 1302
WEIGHT
2.1
Unladen weight (with battery)
kg
1510 1645
2.2
Load per laden axle, drive side / load
side
kg
530 / 1480 380 / 2265
2.3
Load per unladen axle, drive side /
load side
kg
780 / 730 890 / 755
WHEELS
3.1
Tyres Polyurethane Polyurethane
3.2 Drive wheel sizes
Øxl (mm)
Ø250x100 Ø250x100
3.3
Wheel sizes, load side
Øxl (mm)
Ø250x80 Ø250x80
3.5
Number of wheels, drive side/load
side (x = drive wheel)
1x /2 1x /2
3.6
Track width, drive side
b
10
(mm)
00
3.7
Track width, load side
b
11
(mm)
679 679
DIMENSIONS
4.2
Lowered mast height
h
1
(mm)
1650 / 2200 1650 / 2200
4.3
Height of initial lifting h
2
(mm)
150 150
4.4
Lift height h (mm)
1250 1250
4.5
Overall extended mast height h
4
(mm)
1650 1650
4.8
Seat/platform height h
7
(mm)
146 146
14
6 50108043033 [EN]
