Maintenance 6
Maintenance as required
7071_003-070
1
1
2
– Loosen the 2 clamps (1) on the air filter
housing.
– Remove the air filter cover (2).
3
7071_003-114
– Remove the main cartridge (3).
CAUTION
Risk of engine damage!
The safety cartridge must remain in the air filter
housing until all residual dirt has been removed
from the housing so that no dirt enters the induction
system!
– Blow out the air filter housing using com-
pressed air.
171673 [EN] 203
