Operation 5
Start-up
2 3 6 0,4 h
3
12 : 15
59 %
7311_560-004
1
2
Setting the traction programs
The driving and braking response of the drive
can be set on the display and operating unit.
– Press the traction programme key (1) un-
til the number of the desired traction pro-
gramme appears on the (2) display.
Traction programs 1-5 are available.
The basic principle is that the higher the trac-
tion program number is, the greater the trac-
tion dynamics.
The following settings are possible:
Traction program
1 2 3 4
5
Speed (km/h)
21 21 21 21 21
Acceleration (%) (forward / backward)
50 100 120 140 160
Deceleration (%) (forward / backward)
50 100 120 140 160
Reversing (%) (forward / backward)
50 100 120 140 160
Brake retardation (%) (electric brake booster)
80 90 100 100 100
171673 [EN] 75
