7 Technical data
VDI datasheet
Basic dimensions
R70-40T R70-45T R70-50T
Tilt lift mast/fork carriage, for-
wards/backwards
Degree
6/8 6/8 6/8
Height with lift mast retracted h1 (mm)
2400 2400 2400
Free lift
h2 (mm)
160 160 160
Lift height h3 (mm)
3180 3180 3180
Height with lift mast extended h4 (mm)
4187 4187 4187
Height to top of overhead guard h6 (mm)
2300 2300 2300
Sitting height
h7 (mm)
1176 1176 1176
Coupling height h10 (mm)
493 493 493
Total length l1 (mm)
4027 4085 4130
Length including fork back l2 (mm)
3027 3085 3130
Total width b1 1380 1506 1506
Fork arm dimensions
s/e/l (mm
50/120/1000 50/120/1000 50/150/1200
Fork carriage according to ISO
2328 Class/Form A, B
Category III
/FormA
Category III
/FormA
Category III
/FormA
Fork carriage width b3 (mm)
1310 1310 1410
Ground clearance with load under
lift mast
m1 (mm)
140 140 140
Ground clearance at centre of
wheelbase
m2 (mm)
165 165 165
Aisle width for pallet 1000 x 1200
crosswise
Ast (mm)
4418 4470 4510
Aisle width for pallet 800 x 1200
longitudinal
Ast (mm)
4618 4670 4710
Turning radius Wa (mm)
2678 2730 2770
Smallest pivot point distance
b13 (mm)
680 680 680
Performance data
R70-40T R70-45T R70-50T
Driving speed with/without load
km/h 21/21 21/21 21/21
Lifting speed with/without load
min. fan speed
m/s 0.51/0.55 0.43/0.46 0.43/0.46
250 171673 [EN]
