Still R70-45T User Manual

Circuit diagrams 8
Hydraulics
1 Steering cylinder
2 Steering unit
3 Priority valve
4 Variable pump
5 Hydraulic oil tank
6 Breather plug
7 Return line filter
8 Suction screen
9 3-way directional control valve block
10 4-way directional control valve block
11 Burst pipe protection
12 Lift cylinders
13 Tilt cylinder
14 Lowering brake
15 Accumulator tank
16 Pressure reducing valve with housing
17 Fan motor
171673 [EN] 257

Still R70-45T Specifications

General

Brand	Still
Model	R70-45T
Category	Forklifts
Language	English
