Still R70-45T User Manual

8 Circuit diagrams
Electrical equipment
2S6 Lift end limit switch
2S7 Lift end limit switch
2S8 Lift end limit switch
2T1
Charging current transformer
2U1
Pump current actual-value sensor
2V1
Main thyristor pump control
2V2
Gate turn-off thyristor pump control
2V3
Charge reversal thyristor pump
control
2V4
Free-wheeling diode pump control
2X1
42-way SAAB connector plug
2X2
Hydraulic control unit CAN bus plug
2X3
Hydraulic control unit CAN bus plug
2Y1
Directional control solenoid valve (lift)
2Y2
Directional control solenoid valve
(lower)
2Y3
Directional control solenoid valve (tilt)
2Y4
Directional control solenoid valve (tilt)
2Y5
Auxiliary hydr. directional control
solenoid valve 1
2Y6
Auxiliary hydr. directional control
solenoid valve 1
2Y7
Auxiliary hydr. directional control
solenoid valve 2
2Y8
Auxiliary hydr. directional control
solenoid valve 2
2Y9 Release valve
2Y10
Valve on fork carriage
2Z1 Protective circuit for 2V1
2Z2
Protective circuit for 2V2
2Z3
Protective circuit for 2V3
2Z4
Protective circuit for 2V4
Auxiliary drives
3A1
Power-assisted steering control unit
3A2
Control motor injection pump printed
circuit board
3B1
Steering transmitter
3C1
Quenching capacitor
3F1 Fuse for 3M1
3F2 Fuse for 3M2
3K1
Steering motor contactor
3K2
Compressor contactor
3M1
Power-assisted steering motor
3M2
Compressor motor
3M3
Control motor injection pump
3S1
Air supply switch
Signal devices
4A1 not used
4F1 Fuse
4F2 Fuse
4H1 Alarm horn
4H2 Buzzer
262 171673 [EN]
