Operation 4
Procedure in emergencies
– Return the hexagon socket wrench to the
support mounting in the compartment.
– Install the valve cover.
DANGER
If the truck is operated with the hydraulic controller
blocked, there is an increased risk of accidents!
– After the emergency lowering procedure, have
the malfunction rectified.
– Notify the authorised service centre.
3
6210_003-051_V3
Emergency operation of the electric
parking brake
WARNING
The truck can roll away when the parking brake is
released!
Emergency operation of the parking brake can be
initiated only when the fork is lowered and the truck
is switched off.
In emergency operation or during transport
without a battery, the electric parking brake
can be operated manually via the hand wheel.
– Lower the forks to the ground.
– Switch off the
key switch.
– Lift cover (3) and move it to the side.
6210_003-053_V2
4
– Remove hand
wheel (4) and place upside
down on the t
appet.
171
533 EN - 02/2019 - 19 299
