Still RX60-45 - Four-Way Mini-Lever

3 Overviews
Operating devices and display elem
ents
Four-way mini-lever
5060_003-088
1
2
3
4
5
6
7
8
9
10
1 "Lift/lower"
operating lever
2 "Tilt" opera
ting lever
3 Function ke
yF1
4 Function k
ey F2
5 "Drive di
rection / turn indicator" cross lever
6Functionkey"
5th function"
7 "Auxiliary h
ydraulics 1" operating lever
8 "Auxiliary
hydraulics 2" operating lever
9 Emergency
stop switch
10 Signal ho
rn button
NOTE
Depending on the specification, various
electric attachment parts can be controlled
via function keys (3) and (4). Changes must
only be made by the authorised service centre.
