Operation 4
Replacing and transporting the bat
tery
6210_600-001
– Close the battery cover. When doing so,
ensure that no cables are crushed between
the chassis and the battery cover.
The truck is equipped with a do
or contact
switch for the battery cover.
If the battery
cover is not fully closed, the
message
CLOSE
THE DOOR
appears on the displ
ay of the
display-operating unit. Th
e truck will not
move.
Replacing and transporting the battery
General information on replacing the
battery
CAUTION
Risk of components being damaged by the lifting
accessory and battery rolling away!
The lifting accessory and battery may roll away in an
uncontrolled manner if the battery is not removed
on a level, smooth floor with sufficient load-bearing
capacity.
– Follow the operating instructions for the lifting
accessories used.
– Always remove the battery on a level, smooth
floor with sufficient load-bearing capacity.
The battery can be removed using the follo-
wing lifting accessories:
•Truck
• Change frame (variant)
• Hydraulic drive
The load capacity of the lifting accessory used
must at least match the battery weight (see
battery identification plate).
171
533 EN - 02/2019 - 19 333
