Definition of directions
The directions "forwards" (1
), "backwards" (3),
"right" (2) and "left" (4) ref
er to the installation
position of the parts as seen f
rom the driver's
compartment; the load is to th
e front.
Schematic views
6210_003-062
View of functions and operations
This documentation explains the (usually
sequential) chain of certain functions or oper-
ations. Schematic diagrams of a counterbal-
ance truck are used to illustrate these proce-
dures.
NOTE
These schematic diagrams are not represen-
tative of the structural state of the documented
truck. The diagrams are used solely for the
purpose of clarifying procedures.
