If you’ve turned off CarPlay in Screen
Time, go to Settings > Screen Time
> Content & Privacy Restrictions. If
you’ve turned on Content & Privacy
Restrictions, tap Allowed Apps and
conrm that CarPlay is enabled.
(Tap the button until it’s green.)
Conrm Siri is turned on
CarPlay won’t work unless Siri®
is turned on. To turn it on, go to
Settings > Siri & Search on your
iPhone, then conrm that Listen for
“Hey Siri” is on.
Make sure to include the Allow Siri
When Locked option, too, so that
CarPlay works when your iPhone
is locked.
Make sure Bluetooth is connected
If you’re using a wireless CarPlay
connection, go to Settings >
Bluetooth to conrm that Bluetooth®
is turned on. Then go to Settings
> Wi-Fi to check that Wi-Fi is also
turned on. Finally, go to Settings >
General > CarPlay and check that
Auto-Join is turned on.
Check your USB cable
Make sure the wire isn’t frayed or
broken. Try using it with another
device—if it doesn’t work, you
probably have a faulty USB cable
and need to replace it. Also, make
sure you’re plugged into the correct
USB-C port for phone projection.
Apple CarPlay
Android Auto
Restart your Phone
A common rst step to take when
you’re having connection issues is
to restart your device.
1. Turn your phone off.
2. Wait 30 seconds.
3. Turn your phone back on
Make sure your operating system
is up to date
You can nd your device’s Android
version number, security update
level, and Google Play system
level in your Settings app. You’ll
get notifications when updates
are available for you. You can also
check for updates there as well
For step by step instructions,
visit https://support.google.com/
android/answer/7680439
Make sure Bluetooth is connected
If you’re using a wireless Android
Auto connection, go to Settings >
Bluetooth to conrm that Bluetooth®
is turned on.
Check your USB cable
Not all USB cables will work with
all cars. For the best quality and
reliability when you connect to
Android Auto try a high-quality
USB cable.
®
stingersolutions.com
49
General
Operating Voltage: 10.5VDC to 16VDC
Grounding system; Negative Ground
Max current consumption: 15A fused
Dimensions
Display:
178 mm X 87.8 mm X 100mm
(W x H)
Display
6.8-inch Diagonal
16:9 aspect ratio
1024 x 600
Pixels: 614400
Active area 151.76 (W) x 79.8 (H) mm
Operating Temperature (C) -20° to 70°
Audio
Load impedance: 4Ω nominal / 2Ω
allowable
Continuous power output:
18W x 4ch/4Ω 20Hz to 20KHz, 1%THD at
14.4V
Speaker level adjustment: 0-40 steps
Audio Preamp Output level: 3 Vrms
typical.
Audio Preamp 6 Channels: Front
Left, Front Right, Rear Left, Rear Right,
Subwoofer Left, Subwoofer Right.
Equalizer: (13-band)
63Hz/100Hz/160Hz/250Hz/400
Hz/630Hz/1KHz/1.6KHz/2.5KHz/4KHz/6.3K
Hz/10KHz/16KHz
Gain: ±6dB (0.5dB/step)
Crossover level: 13 steps
Front output:
HPF: 25Hz/40Hz/63Hz/80Hz/100Hz/160H
z/250Hz/500Hz/1kHz/3.5kHz/5kHz/bypass
Slope: 6dB, 12dB, 18dB
Level: 0-12
Rear Output:
HPF: 25Hz/40Hz/63Hz/100Hz/250Hz/
bypass
Slope: 6dB, 12dB, 18dB
Level: 0-12
Subwoofer Pre-lineout: 3Vrms typical.
LPF: 25Hz/40Hz/63Hz/100Hz/250Hz/bypass
Slope: 6dB, 12dB, 18dB
Subwoofer level: 0-15
Phase: 0 or 180
Time Alignment for 6 channels: 0 to
133 steps for inches and 0-99 steps for
9.9ms/133inches.
User Preset EQ: Rock, Hip-Hop,
Electronics, Jazz, Pop, Flat.
Source Gain: default 0db, -10 to 10
adjustable, 0.35db/Step.
Volume Settings: Main Volume, Phone
Volume, Navigation Volume, Voice
Volume, Ringtone Volume adjustable
separately.
SPECIFICATIONS
