SatLink VSAT User Guide
Publication no. 101557
Copyright © 2009 – STM Group, Inc.
Page 130 (160)
Figure 47: Mounting feed horn
Insert the remaining screws and tighten firmly with an Allen key. Always use screws from mounting kit
supplied with the STM SatLink 4033/4035 (part no. 105773). Do not use other screws or apply washers!
Figure 48: Tightening with Allen key
