AN4989 Rev 3 15/118
AN4989 STM32 ecosystem outlines
117
KEY FEATURES
• STM32L496VGT6 microcontroller featuring Arm
®
Cortex
®
-M4 core at 80 MHz / 100
DMIPS and three 12-bit ADC at 5 Msps
• Programmable voltage source from 1.8 V to 3.3 V
• Static current measurement from 1 nA to 200 mA
• Dynamic measurements:
– 100 kHz bandwidth, 3.2 Msps sampling rate
– Current from 100 nA to 50 mA
– Power measurement from 180 nW to 165 mW
– Energy measurement computation by power measurement time integration
– Execution of EEMBC ULPMark™ tests
• Mode standalone:
– Monochrome LCD, 2 lines of 16 characters with backlight
– 4-direction joystick with selection button
– Enter and Reset push-buttons
• Mode controlled:
– Connection to a PC through USB FS Micro-B receptacle
– Command line (Virtual COM port) or
– STM32CubeMonitor-Power PC tool.
• Four status LEDs
• Target board connectors:
– ARDUINO
®
Uno and Nano connectors
– Basic connector (white): 4 wires
• Flexible input power-supply options:
– USB Micro-B (VBUS)
– External power connector (7 V to 10 V)
– ARDUINO Uno and Nano connectors (pin 5 V)
