27
Electrical data of the machine
3
Electrical data
CMS 502
Machine dimensions (in cm)
Machine dimensions (in cm)
The back-and-forth movement of the carriage causes the dynamic loads listed
above to occur at the set screws.
Dimensions, weight and dynamic weight
Dimensions, weight and dynamic weight
Electrical data
A Width B Depth C Height
D Spacing of set screws E Nominal working width
A B C D E Weight (kg) Dynamic
weight (kg)
CMS 502 237 92 205 140 114 1025 470
