66
7 Assembly and setting up
Assembling machine
7.2.7 Mounting signal light
The power supply for the yarn control devices and the
signal light are moved into the supports when the knitting
machine is shipped. The signal light from the accessories
needs only be connected and screwed into place.
Signal light
Signal light
Carefully tighten the fastening screw of the signal light to
prevent the plastic holder from being damaged.
T
he main switch is set to "0" and secured against being switched on
again.
1. Plug the power cable from the r
ight support into the signal light (1).
2. Screw on the signal light onto the ri
ght support with the screws present
there.
Mounting friction fee d wheel
