Stoll CMS 502 - Rear Side

35
Main components of the knitting machine
4
Rear side
Rear side
4.3 Rear side
Rear side (without rea r panel segments)
Rear side (without rear panel segments)
No. Label No. Label
1 Carriage 5 Fluff absorption
2 Rear Needle Bed 6 Control unit on the right
3 Trailing cable (energy chain) 7 Main drive
4 Transformer (Fuses) 8 Racking device
