69
Assembly and setting up
7
Assembling machine
7.2.10 Aligning knitting machine
Keys for aligning the machine
Key
Function
Call up the "Service" menu
Call up "Reference runs" window
Call up "Main menu"
1. Turn the main switch at the front of the machine to 1.
2. Tap on the "Warm start" key.
3. Call up the "Service" menu from the "Main menu".
4. Call up the "Reference r
uns" windo
w.
Reference runs window
"Reference runs" window
5. Tap the "S>" key in the "Direction of carriage movement" field.
DANGER
Danger by moving carriage!
Danger of crushing and cutting by the carr
iage.
➜ Close the covers.
6. P
ull up engaging rod. The carriage moves at creep speed to the righ
t and
carries out a reference run.
