6 Optical and acoustic signal elements
Horn
Pictographs for the display of stop motions
Horn
6.3 Horn
An alarm signal is produced in the following situations:
if the machine
stops because of an error
approx. 60 seconds after this the main swit
ch gets rotated to "0"
The alarm signal can be switched on and off (standard
setting = off).
Belt take-down
Friction feed wheel on
the left
Friction feed wheel on
the right
Lubrication
Greasing (ultra coarse
machine)
Front racking
Rear racking
Power failure
Needle stop left
Needle stop centre
Needle stop right
Piece counter
miscellaneous causes of
stop motion
Pictographs
