Assembly and setting up
7
Assembling machine
7.2.5 Plug in battery pack
The battery pack is unplugged and not charged completely on delivery of the
machine.
Plug in battery pack:
 The main switch is switched off.
1. Open the cover on the control unit.
2. Plug in battery pack.
3. Close the cover.
