Storm Audio ISP MK2 - Specifications

40
Control
Control Modules Crestron and Crestron Home
Control4
RTI
Savant
ELAN
IR Front panel sensor
Rear panel I/O, jack 3.5mm
DC Trigger x4, jack 3.5mm
Software assignable to
inputs, presets, on/standby
or manual operation
Applications WebUI: Setup & remote
control
iOS App: remote control
Android App : remote control
Network 100 Mbps Ethernet
Power Supply
Type Universal
Range 100 to 240V, AC signal
Weight and Dimensions
(net product)
L x W x H (cm / inches)
rack ears mounted
49,00 x 47,90 x 19,10
19.29 x 18.86 x 7.52
Weight 13,10 KG | 28.80 LBS
Options
UMIK-1 Microphone USB microphone.
Allows for Monitoring,
Calibration and RTA function.
16 to 24ch XLR Output Extra 8 channel XLR output
module (24ch total)
24 to 32ch XLR Output Extra 8 channel XLR output
module (32ch total)
16 to 32ch XLR Output Extra 16 channel XLR output
module (32ch total)
32ch Digital AES Output 32 channel AES/EBU output
module (4x RJ45)
32ch Digital AoIP
Input/Output
32 channel AES67 I/O module
(2x RJ45)
16ch Digital AES Input 16 channel AES/EBU input
module (2x RJ45)
DCI compatible
Specifications
Audio
Audio Formats up to 24ch (13.1.10), 192 kHz
Dolby Atmos with Enabled
Speakers, DTS:X Pro,
IMAX Enhanced*, Auro3D
All Legacy codecs
StormXT
SphereAudio for
headphones
Audio Inputs 16ch (AES/EBU) optional
32ch (AoIP) optional
4x RCA analog (7.1 or 2.0)
1x XLR analog (stereo)
3x Coaxial (SPDIF)
3x Optical (Toslink)
Streaming ROON Ready
Post-Processed Outputs up to 32ch, 48 kHz
Audio outputs 16ch analog (XLR) default
24ch or 32ch analog (XLR)
optional
32ch digital (AES/EBU or
AoIP) optional
1x XLR Stereo (Downmix)
Bass Management Multiple individual
subwoofers
Per channel crossover
Standard and Expert
Up to 6 Bass Zones
Multi-way speaker XO Up to 4-Way speakers
6, 12, 18, 24, 36, 48 dB/Oc-
tave, Linkwitz-Riley and
Butterworth
Equalization per Channel up to 20 band PEQ
REW plugin
Calibration Dirac Live with
Bass Control module
*via firmware upgrade in 2022
HDMI
Inputs / Outputs 7 / 2, matrix*
Input Specs 7 ea. HDCP2.2 / HDMI2.0
Output Specs 2 ea. HDCP2.2 / HDMI2.0
ARC/eARC on HDMI Out1
On Screen Display
Max Resolution UHD, 4K 60fps 4:4:4 8bpc
18 Gpbs all ports
HDR HDR10, HLG & Dolby Vision
Deep Color Support 12bpc
CEC ARC related only
*via firmware upgrade in 2022
