Objet500 User Guide 6 Operating and Maintaining the Objet500 3DPrinter
DOC-07027 Rev.E 6-36
8. Cleantherollerwastecollectorandthescraperbladesurfaceusingcotton
swabs.Makesuretoremoveanyremainingprintingmaterials.
Figure6-39Cleaningtherollerwastecollector
Beforereplacingthecovering,youcanchecktheeffectivenessoftheroller
scraper—seebelow.
Tochecktheeffectivenessoftherollerscraper:
1. Putonthecleaninggloves.
2. Wetaclothwithisopropanol.
3. Usetheclothtowetthebottomoftheroller.
4. Turntherollerslowlywithyourhand.Asthebladescrapestheroller,
makesuretheisopropanolisspreadevenlyovertheentirelengthofthe
blade.
5. Inspecttheroller.Ifitisnotdry,replacetheblade.(See"Replacingthe
RollerScraper"onthenextpage.)
6. Beforereturningtherollerwastecollectortotheprintblock,makesure
thatthepinsareclean.
Figure6-40Rollerwastecollectorpins
Tore-assemblethecomponents:
1. Returntherollerwastecollectortotheprintblockandscrewonthe
covering(seeFigure6-38onthepreviouspage).
