Objet500 User Guide 6 Operating and Maintaining the Objet500 3DPrinter
DOC-07027 Rev.E 6-64
Figure6-92LabelonthebottomoftheUVsensorbox
ThebuildtraylowerssoyoucanconnecttheUVsensorbox.
Figure6-93UVsensorconnector
2. ConnecttheUVsensorcabletotheconnectorintheprinter.
Toensurethatthesensorcabledoesnotinterferewiththebuildtraywhen
itisraised,routeitinbackofthesensor.
