STRONG HD STB User’s Manual
10
E. CVBS (Composite – For SD) via the supplied Y
ellow / White / Red RCA Lead
For this Standard Definition Composite Video connection, Audio is also included, this will
be PCM Stereo.
F. Connecting the Antenna
Connect TV Antenna to Connector 1 (Aerial)
Audio Connections
PCM Stereo – V
ariable : Using supplied Yellow / White / Red RCA Lead
(Other than when connecting for CVBS Composite, the Yellow RCA will not be required to be
connected)
If you require Dolby Digital Audio Output (through you’re Dolby Digital Decoder Amplifier)
please refer to : DOLBY DIGITAL AUDIO (page 11)
Connector 3
(Yellow)
Connector 4
(White)
Connector 5
(Red)
VIDEO
AUDIO Left
AUDIO Right
RCA cinch
RCA cinch
RCA cinch
Connect to Video (Yellow) RCA
of your TV
Connect to audio (White) RCA
of your TV
Connect to audio (Red) RCA of
your TV
Connector 4
(White)
Connector 5
(Red)
AUDIO Left
AUDIO Right
RCA cinch
RCA cinch
Connect to audio RCA input
(White) of your TV
Connect to audio RCA input
(Red) of your TV
Connector 7
(Red)
Connector 8
(White)
AUDIO Right
AUDIO Left
RCA cinch
RCA cinch
Connect to audio RCA input
(White) of your TV
Connect to audio RCA input
(Red) of your TV
PCM Stereo – Fixed Using supplied Y
ellow / White / Red RCA Lead
Refer Page 22: 2
nd
Audio Volume Mode
(Other than when connecting for CVBS Composite, the Yellow RCA will not be required to be
connected)
Connector 1 Aerial IEC169-2
female
Input from Antenna to Receiver
