4-2 Climate control
Ventilator control
& Center ventilators
1) Open
2) Close
Move the tab to adjust the flow direction.
To open the ventilator, turn the center grille
open/close wheel to the “
” position.
To close it, turn the wheel to the “
”
position.
& Side ventilators
1) Open
2) Close
Move the tab to adjust the flow direction.
To open the ventilator, turn the side grille
open/close w heel upward to t he “
”
position.
To close it, turn the wheel downward to the
“
” position.
