CAUTION
The arrow mark on the filter must
point UP.
6. Reinstall the glove box, and connect
the damper shaft.
7. Close the glove box.
8. LABEL installation
(1) Fill out the information on the
service label (small).
1) Service label
(2) Attach the service label to the
driver’s side door pillar.
1) Caution label
(3) Attach the caution label on the
driver’s side of the instrument panel as
shown in the illustration.
Climate control 4-11
4
