Fuse
panel
Fuse
rating
Circuit
13 15A
. Engine control unit
14 15A
. Ignition coil
15 15A
. Engine control unit
16 15A
. Engine control unit
17 15A
. Automatic transmission
control unit
18 10A
. Illumination
19 10A
. Rear combination light
20 15A
. Turn and hazard warn-
ing flasher (body control
unit)
21 20A
. Door lock (body control
unit)
22 15A
. Rear wiper
. Rear washer
23 10A
. Front washer
24 30A
. Front wiper
25 25A
. Rear window defogger
. Mirror heater
. Front wiper deicer
26 15A
. Blower fan
27 15A
. Blower fan
Fuse
panel
Fuse
rating
Circuit
28 25A
. Audio unit
29 25A
. Sub fan
30 25A
. Main fan
31 30A
. ABS/Vehicle dynamics
control unit
32 10A
. Fog light (right side)
33 10A
. Fog light (left side)
34 10A
. Back-up (body control
unit)
