Sukup Sweepway - Page 59

Parts/Assemblies
59
25° INCLINE AUGER FOR 6” UNLOAD
REF. #
DESCRIPTION
QTY.
6” PART #
1
5’ basic incline
1
E5950
2
Flighting & auger tube
1
E5622
3
Incline shaft
1
E56421
4
Shaft
1
E54151
5
Shaft, auger to knuckle
1
E56411
6
Hinged motor mount
1
E5746
7
Small pivot rod
1
E5744
8
10” clamp band, narrow
1
E97161
9
Key, 1/4”
2
F4499
10
Tube mount
1
E5958
11
Bushing support
1
E5956
12
Knuckle
1
E5980
13
Outer shield
1
E5973
14
Inner shield
1
E5972
15
Shield bracket
2
E9316
16
Adapter plate
1
E5953
17
Adapter sleeve mount
1
E5954
18
Key, 1/4" x 2-3/4”
1
E5721
19
Connector sleeve
1
E5423
20
Flange bearing w/ locking collar, 1-1/4”
1
J0010
21
Bushing, 1” x 1-1/4” x 1-1/4”
1
J00811
22
Belt, BX54
2
J0227
23
Pulley, 14 x 1-1/4”, double “B” groove
1
J03951
24
Spacer, 3/8”
1
E5739
25
Bolt, 5/16 - 18 x 1”
10
J0527
26
Bolt, 5/16 - 18 x 1-1/4”
16
J0550
27
Bolt, 3/8 - 16 x 1”
2
J0606
28
Screw, 3/8 - 16 x 2-1/2”
2
J0655
29
Bolt, 3/8 - 16 x 3”
6
J0660
30
Bolt, 7/16 - 14 x 2”
4
J0718
Bolt, 1/2 - 13 x 3”
4
- - -
31
Bolt, 1/2 - 13 x 1-1/2”
2
J0730
32
Bolt, 3/4 - 10 x 6”
1
J0824
33
Hex nut, 5/16” – 18
20
J1002
34
Hex nut, 3/8” – 16
8
J1020
35
Lock nut, 3/8” - 16
4
J1025
36
Lock nut, 7/16” – 14
4
J1034
Lock nut, 1/2" – 13
4
- - -
37
Nut, 1/2" – 13
2
J1040
38
Nut, 3/4" - 10,
1
J1051
39
Flat washer, 5/16”
12
J1111
40
Split lock washer, 5/16”
12
J1200
41
Split lock washer, 3/8”
2
J1205
42
Split lock washer, 1/2"
2
J1215
43
Hairpin clip, .120 x 2.5
2
J5412
44
Screw, 5/16 – 18 x 1/2”
4
J0519
