Sukup Sweepway - Page 62

Parts/Assemblies
62
25° INCLINE AUGER FOR 8” UNLOAD
(E5032 – 3-belt)
REF. #
DESCRIPTION
QTY.
PART #
1
Brace
2
E5023
2
Plate
1
E5025
3
Transition
1
E5033
4
Tube
1
E5034
5
Bearing support
2
E5035
6
Intermediate shaft
1
E5036
7
Bearing assy.
2
E5037
8
Auger shaft
1
E5038
9
Auger, 45-1/2”
1
E5039
10
Transition cover
1
E5040
11
Auger, 9" OD, 5"
1
E5041
12
Tube clamp, 2 x 17"
1
E5407-02
13
Shaft, 18"
1
E54142
14
Shaft, 8-1/2”, w/ key
1
E5624
15
Spacer, 3/8"
2
E5739
16
Pivot rod
1
E57441
17
Motor, mount
1
E5765
18
Shield, inner
1
E5972
19
Shield, outer
1
E5973
20
Shield bracket
2
E5974
21
Knuckle
2
E5980
22
Key, 1/4” sq. x 2
4
F4499
23
Flange brng., 1-1/4”, w lock collar
1
J0010
24
Screw, 5/16 – 18 x 1”
18
J0527
25
Screw, 5/16 – 18 x 1-1/4”
4
J0550
26
Screw, 3/8 – 16 x 1”
8
J0611
27
Screw, 3/8 – 16 x 2-1/2”
4
J0655
28
Screw, 3/8 - 16 x 3”
2
J0660
29
Screw, 1/2 – 13 x 1-1/2”
6
J0730
30
Screw, 1/2 – 13 x 3”
9
J0750
31
Screw, 3/4 - 10 x 6”
1
J0824
32
Nut, 5/16” – 18
14
J1002
33
Flange lock nut, 3/8” - 16
10
J1017
34
Lock nut, 3/8” – 16
4
J1025
35
Nut, 1/2" – 13
2
J1040
36
Lock nut, 1/2" – 13
13
J1042
37
Nut, 3/4" – 10
1
J1051
38
Flat washer, 5/16”
8
J1111
39
Flat washer, 3/8”
2
J1117
40
Flat washer, 1/2"
2
J1125
41
Split lock washer, 5/16”
22
J1200
42
Lock washer, 1/2”
2
J1215
43
Machine bushing, 3/4 x 1-1/4”, 14ga
10
J1260
44
Bushing, rubber, 1/2" ID
4
J5021
45
Hairpin clip, .120 x 2.5
2
J5412
46
Decal, Do Not Enter Bin, Keep Clear of Augers
1
L0258A
47
Decal, Danger, Replace Missing Shield
2
L0271
48
Decal, Safe Operation
2
L0281
49
Decal, Keep Away From Moving Parts
2
L0284
50
Sukup logo
2
L03161
51
Hinge spacer, 2.438"
1
E5740
