Parts/Assemblies
66
6” SWEEPWAY CENTER SUMP
REF. #
DESCRIPTION
QTY.
6” PART #
1
Center sump shell
1
E5300
2
Center sump cover
1
E5306
3
Center sump brace
2
E5308
4
Chain cover
1
E5309
5
Gearbox support cover
1
E5312
6
Clutch shifter arm assembly
1
E5313
7
Top gearbox bearing support slide plate w/ bearings
1
E5317
8
#50 chain, 73 links & 1 connector link
1
E5319
9
Lower gearbox
1
E5320
10
Spacer washer, 3/8” ID, 2-1/4” OD
1
E5324
11
Top gearbox
1
E5325**
12
Slide gate
1
E5476
13
Bolt, 7/16 - 14 x 2”
2
E5570
14
Sprocket, 1” bore, 50B18
1
E5837*
15
Key, 1/4” sq. x 1”
2
E5915
16
Three-tooth engaging clutch
1
E60011
17
3-bolt clutch base
1
E6002-01
18
Clutch base w/ set & pilot bearing, 2 bolt
1
E60031
19
Clutch spacer, 5/8” long
2
E60041
20
Clutch spacer, 7/16” long
1
E60042
21
Mounting plate
1
E6005
22
Square-end shaft
1
E6006
23
Key, 1/4” x 1-1/2”
1
E9007
24
Key, 1/4" x 3/4”
1
G7508
25
1” flange bearing
1
J0003
26
Roller bearing 1-1/2”, 3/8” bore
6
J0045
27
Bolt, 5/16 - 18 x 3/4”
3
J0520
28
Screw, 5/16 - 18 x 1”
2
J0527
29
Carriage bolt, 5/16 - 18 x 2-1/2”
3
J0589
30
Bolt, 3/8 - 16 x 1”
4
J0606
31
Bolt, 3/8 - 16 x 1-1/4”
2
J0616
32
Bolt, 3/8 - 16 x 1-1/4”, zinc plated
1
J06161
33
Stud bolt, 7/16 - 14 x 2-3/4”
4
J07211
34
Bolt, 1-1/2 x 1/2”
3
J0730
35
Hex nut, 5/16” - 18
8
J1002
36
Flat nut, 5/16” - 18
1
J1009
37
Lock nut, 3/8” - 16
7
J1025
38
Hex nut, 7/16” - 14
2
J1035
39
Flat washer, 5/16”
2
J1111
40
Flat washer, 3/8”
7
J1117
41
Washer, 2-1/2” OD, 3/8” ID, 14ga
1
J1140
42
Split lock washer, 5/16”
8
J1200
43
Split lock washer, 3/8”
5
J1205
44
Split lock washer, 7/16”
2
J1210
45
Machine bushing, 1”, 18ga
2
J1266
46
Allen-head setscrew, 1/2 x 1-1/4”
2
J1390
47
Sprocket, 50B15H, 1” bore w/ keyway
1
J1665
48
Chain connector link, #50
1
J1760
*Order E58371 to receive setscrews with sprocket
**Order E53393 to receive assembled gearbox, bearing plate & sprocket
