Parts/Assemblies
70
10" SWEEPWAY CENTER SUMP
REF. #
DESCRIPTION
QTY.
PART #
1
Clutch shifter arm assembly
1
E53132
2
Spacer washer, 3/8” ID, 2-1/4” OD
1
E5324
3
Weld support plate w/ snap ring, 10"
1
E5339
4
Side gate rail
2
E5350-14
5
Sump cover
1
E5354
6
Gearbox support cover
1
E5357
7
Chain cover
1
E5358
8
Lower gearbox
1
E5360
9
Sprocket, 60B20, 1.1811” bore
1
E5373*
10
Top gearbox
1
E53751**
11
Center sump shell
1
E5377
12
Gearbox support angle brace
1
E53874
13
Slide gate
1
E5478
14
Key, 1/4 sq. x 1"
2
E5915
15
Three-tooth engaging clutch
1
E60011
16
3-bolt clutch base
1
E6002-01
17
Clutch base w/ set & pilot bearing, 2 bolt
1
E60031
18
Clutch spacer, 5/8” long
1
E60041
19
Clutch spacer, 7/16” long
1
E60042
20
Mounting plate
1
E60051
21
Square-end shaft
1
E6018
22
Key, 1/4 x 1-1/2”
1
E9007
23
#60 chain, 69 links
1
EU0139
24
Key, 1/4" x 3/4”
1
G7508
25
1” flange bearing
1
J0003
26
Roller bearing 1-1/2”, 3/8” bore
10
J0045
27
Bolt, 5/16 - 18 x 3/4”
3
J0520
28
Carriage bolt, 5/16 - 18 x 2-1/2”
3
J0589
29
Bolt, 3/8 - 16 x 1-1/4”
4
J0616
30
Bolt, 3/8 - 16 x 1-1/4”, zinc plated
1
J06161
31
Screw, 7/16 - 14 x 1-1/2”
2
J0710
32
Stud bolt, 7/16 - 14 x 2-3/4”
4
J07211
33
Screw, 1/2 - 20 x 1-1/4”
8
J0724
34
Screw, 1/2 - 13 x 1-1/4”
1
J0728
35
Bolt, 1-1/2 x 1/2”
3
J0730
36
Hex nut, 5/16” - 18
6
J1002
37
Flat nut, 5/16” - 18
1
J1009
38
Hex nut, 3/8” - 16
2
J1020
39
Lock nut, 3/8” - 16
11
J1025
40
Hex nut, 7/16” - 14
2
J1035
41
Hex nut, 1/2" - 13
1
J1040
42
Setscrew, 5/16” - 18
4
J1080
43
Flat washer, 5/16”
2
J1111
44
Flat washer, 3/8”
11
J1117
45
Flat washer, 1/2”
8
J1125
46
Washer, 2-1/2” OD, 3/8” ID, 14ga
1
J1140
47
Split lock washer, 5/16”
6
J1200
48
Split lock washer, 3/8”
3
J1205
49
Split lock washer, 7/16”
2
J1210
50
Lock washer, 1/2"
9
J1215
51
Machine bushing, 30mm ID x 4mm OD
1
J1268
52
Allen-head setscrew, 1/2 x 1-1/4”
2
J1390
53
Sprocket, 50B14, 1-1/4” bore
2
J1667
54
Sprocket, 60B13, 1-1/4” bore
1
J1686
55
Double chain link connector, #50
1
J1761
56
#60 chain connector link
1
J1775
57
Double chain, #50, 13 links
1
S7023
*Order E53731 to receive setscrews with sprocket
**Order E53394 to receive assembled gearbox, bearing plate & sprocket
