Sukup Sweepway - Page 71

Parts/Assemblies
71
INDEPENDENT INTERMEDIATE SUMP
8” & 10”
REF. #
DESCRIPTION
QTY.
PART #
1
Sump bottom
1
E53951
2
Slide gate
1
E53963
3
Sump top
1
E53964
4
Sump bottom
1
E53981
5
Slide gate
1
E53987
6
Sump top
1
E53989
7
Bearing, 1/4" ID, 5/8” OD
10
J0016
8
Screw, 1/4 – 20 x 1”
10
J05081
9
Screw, 5/16 – 18 x 3/4”
1
J0520
10
Hex nut, 1/4" – 20
10
J0990
11
Lock nut, 5/16” – 18
1
J1010
12
Lock washer, 1/4”,
10
J1195
13
Shaft collar, 7/8"
4
J1330
