Sukup Sweepway - Page 82

Parts/Assemblies
82
4-TO-1 REDUCTION DRIVE WHEEL
Standard on all 6” sweeps and on 8” sweeps in bins up to 33’ dia.
REF. #
DESCRIPTION
QTY.
6" COMP #
8" PART #
Complete wheel
E6094
E6092
6” assembly mount, 2010
1
E6095
-
1
8” assembly mount, split, w/ brng., 2010
1
-
E6096
10” assembly mount, split, w/ brng., 2010
1
-
-
2
Back plate w/ roller, 2010
1
E6087
E6087
3
10" rubber ring, 2000
3
E60121-01
E60121-01
4
Back plate, 9.25" Dia., 2010
1
E6088
E6088
5
Drive shaft w/ 8-tooth sprocket
1
E6049
E6049
6
Self-drilling screw, 1/4 - 14 x 2-1/4
6
J05041
J05041
7
Flat washer, 3/4"
1
J1130
J1130
8
Lock nut, 3/4" – 10
1
J1057
J1057
9
Screw, 3/8 - 16 x 1”
4
J0606
J0606
10
Split lock washer, 3/8"
4
J1205
J1205
11
Hex nut, 3/8" – 16
4
J1020
J1020
12
Machine bushing, 3/4 x 1-1/4”, 14ga
2
J1260
J1260
13
Screw, 3/4 -10 x 4-1/2”
1
J0817
J0817
14
Screw, 5/16 - 18 x 1-3/4”
2
J0570
J0570
15
Lock nut, 5/16” – 18
2
J1010
J1010
16
1” flange bearing w/ locking collar
1
J0003
J0003
