16E / 16E-H / 16E-P Spray Gun
28
MAN 96150 EN 01
Manufactured
Gas
3/16
1
12E2-5
(1000259)
12E7-43
(1000286)
3K3-EA
(1000666)
12E7-43
(1000286)
12E7-46
(1000288)
1/8
2
12E2-5
(1000259)
12E7-49
(1000291)
8E3-EC
(1001570)
12E7-49
(1000291)
12E7-27
(1000274)
11 Ga. 12E2-5
(1000259)
12E7-37
(1000282)
4E3-J
(1000835)
12E7-37
(1000282)
12E7-38
(1000283)
15 Ga. 12E2-7
(1000261)
12E7-31
(1000277)
4E3-M
(1000836)
12E7-31
(1000277)
12E7-32
(1000278)
1. For fan spray, use air cap Y4-AB (1002414) with 3/16” wire.
2. For fan spray, use air cap 4E4-CD (1000841) with 1/8” wire.
3. Sprabond wire only.
Standard/Non-Loading Air Cap Equivalency Chart
Standard Air Cap
Equivalent Non-Load Air Cap
Acetylene & Propane MAPP
3K3-EA (1000666) 3K3-AH (1000662) —
3K3-AM (1000663) — —
8E3-EC (1001570) 3K3-CH (1000664) 3K3-CHM (1000665)
4E3-J (1000835) 3K3-JH (1000667) —
4E3-M (1000836)
3K3-JH (1000667)
1
1. If a smaller spray pattern is desired, use 3K3-MH (1000668) in-
stead of 3K3-JH. Operating pressure range of the gun will be re-
duced. Depending on wire being sprayed and spraying cycle,
there may be tendency for some air cap loading.
—
Y3-C (1002413) 3K3-CH (1000664) 3K3-CHM (1000665)
Siphon Plug / Nozzle / Air Cap Selection Chart (Continued)
Normal Spraying
All Wire
Start-Stop Operation
Aluminum & Zinc Alloys
Start-Stop Operation
Babbit, Tin
Low Melting-Point
Alloys
Fuel Gas Wire Size
Siphon
Plug
Nozzle Air Cap Nozzle
Non-Load
Air Cap
Non-Load
Nozzle
Non-Load
Air Cap
To Next Page
