16E / 16E-H / 16E-P Spray Gun
48
MAN 96150 EN 01
3. Install screw (107) through bottom of drive roll carrier (104) and
thread into drive roll axle (105). Tighten screw securely.
4. Install drive roll carrier (104) on spray gun. Make sure that piston
rod of drive roll mechanism engages groove in drive roll carrier.
5. Install pivot pin (105), press and turn counterclockwise to lock.
Lower Drive Roll/Gear Removal
1. Using spanner tool (184) inside cavity of central housing (129),
engage pins with holes in lower drive gear (123).
2. Loosen lower drive gear (123) from drive shaft (173) buy turning
gear clockwise (toward front of spray gun).
3. Once loose, manually unscrew lower drive gear (123) from drive
shaft (173) and remove.
4. Repeat steps 1-3 for lower drive roll (124).
Lower Drive Roll/Gear Installation
1. Place lower drive roll (124) onto drive roll tool (184), reach inside
cavity of central housing (129) and thread lower drive roll onto
drive shaft (173).
2. Use fingers to thread lower drive roll onto drive shaft, counter-
clockwise.
3. Using spanner tool (184), tighten lower drive roll (124) by turning
roll counter-clockwise (toward rear of spray gun).
4. Repeat steps 1-3 for lower drive gear (123). Make sure the gear’s
extended shoulder faces the drive roll.
INFO
The drive shaft and lower
drive gear have left-hand
threads.
i
