Service Manual SummaSign
SENSOR TESTS
The front and rear media sensors can be tested with internal test as described in
section 1.6.4. . To test the media sensors just follow the guidelines on the LCD
screen .
is shown when the sensor is covered.
is shown when the sensor is uncovered. The bottom
arrow has to be at least 2 positions further
than the top arrow for the unit to function properly.
There is a possibility to change the positions of the bottom arrow with the left and
right arrow on the keyboard.
1.
7. C
Calibration 4-13
-------------------------------->
>
