Service Manual SummaSign series Cutters
THE USER CONFIG MENU
The USER CONFIG(uration) menu gives access to different submenus which allow you
to configure the cutter's operating parameters. It should be taken into account that
access to some of the submenus will be determined by the plotting language you are
using.
Four different user configurations can be saved. The selected configuration number is
displayed on the LCD next to the USER CONFIG message. These four USER CONFIG
1(->4) menus are maintained independently.
To select another configuration number, proceed as follows:
1. Power on the cutter.
2. Press the
key until USER CONFIG 1(->4) is displayed.
3. Press the
or jogging key until the desired configuration number is dis-
played next to USER CONFIG.
NOTE
Before altering any of the items in the USER CONFIG menu, make sure
that you have previously selected the right configuration number in the
USER CONFIG 1(->4) menu.
To select and alter a configuration parameter, proceed as follows:
1. Power on the cutter.
2. Press the
key until USER CONFIG 1(->4) is displayed.
3. Press the
or jogging key until the desired submenu is displayed on the
first line of the LCD.
4. Press the
or jogging key until the desired value is displayed on the
second line.
5. Press the
key to confirm the selection, an * will be displayed next to the
selected setting. (An * is always displayed next to the active value. )
Keyboardcontrols 1-9
