SummaSign series Cutters Service Manual
NOTE
It is strongly recommended to produce a MENU PLOT hard copy each time
you alter the cutter configuration. The resulting plot should be kept with the
cutter documentation in order to provide other users with details of the
actual configurations of the unit.
CONFIDENCE CUT
The CONFIDENCE cut performs an electrical and mechanical test of the cutter to make
sure that the cutter is fully operational. A media sheet of at least A3/A- size should be
used for this plot.
DIN CUT
The DIN CUT also performs an electrical and mechanical test of the cutter, in order to
check the cut quality, but also provides the user with feedback on knife setting, knife
pressure, knife offset and cutting depth.
This cut is always run as a DIN A4 portrait/A-size image, regardless of the actual size
of the media loaded. If the media loaded is smaller than DIN A4/A-size, part of the
outer box will be clipped (not cut). This cut is always executed in the sequence
prescribed by the ISO DIN standard.
SYSTEM TESTS
The SYSTEM TESTS submenu covers the menu items you only occasionally need to
adjust the cutting process.
Press the ENTER key to access the different submenu items which are explained in
section 1.6 below.
1-26 Keyboardcontrols
