Summit CC - APPENDIX E - REFERENCE TABLES; TORQUE GUIDELINES

INSTALLATION, OPERATION, AND MAINTENANCE MANUAL
32 SUMMIT PUMP MODEL CCFM GENERAL PURPOSE
15 APPENDIX E – Reference Tables
15.1 TORQUE GUIDELINES
15.1.1 Bolt Torques
Bolt Size
Stainless Steel Bolts
ASTM F593
Carbon Steel Bolts
SAE J429 Grade 5/
ASTM A449
Size
Max. Torque
Max. Torque
10-24
24 inlb
-
10-32
33 inlb
-
1/4-20
45 inlb
100 inlb
5/16-18
92 inlb
17 ftlb
3/8-16
14 ftlb
30 ftlb
7/16-14
22 ftlb
49 ftlb
1/2-13
33 ftlb
75 ftlb
9/16-12
48 ftlb
110 ftlb
5/8-11
66 ftlb
150 ftlb
3/4-10
120 ftlb
265 ftlb
7/8-9
190 ftlb
429 ftlb
1-8
280 ftlb
644 ftlb
Table 15-1: General Max bolt torque values
