1.3 Back Panel Features
The server’s I/O ports and power inlets are on the back panel.
FIGURE 1-8 I/O Ports (Sun Fire V210 Server)
FIGURE 1-9 I/O Ports (Sun Fire V240 Server)
1.3.1 I/O Ports
The I/O ports on the rear of the Sun Fire V210 and V240 servers are arranged as
shown in
FIGURE 1-8 and FIGURE 1-9. For more information on the I/O ports, refer to
the Sun Fire V210 and V240 Servers Getting Started Guide (819-4206-10).
Power inlet
NET MGT
SERIAL (10101)
SERIAL
MGT
Ethernet USB SCSI
Power inlet(2)
SERIAL (10101)
SERIAL
MGT
NET MGT Ethernet USB SCSI
